Beschrijving
Power, reliability and versatility from a single printer
136 column dot-matrix printer
Extremely durable 9 pin printhead with Oki reliability built-in as standard
550 characters per second print speed
Multi-part paper handling (original + 7 copies)
The Microline 3410 is a powerful workhorse that has been designed to handle the most data intensive applications with an extremely high print speed coupled with superior copy capability. Main areas of use are high-volume forms applications such as listings, logistics documents, labels, heavy continuous forms etc. Equally at home in offices, warehouses or industrial production environments this printer can withstand extremes in operating conditions. The Microline 3410 comes with an in-built pushtractor with paper-park function. Available options include bottom power-tractor, mechanical pull-tractor and cut-sheet feeders.
Key specifications
Number of copies:8 (original + 7 copies)
Print speed:Fastest:550 High speed draft @ 10cpi: 550 Data/Letter quality @ 10cpi: 417/104
Printing width:136 characters (10cpi) 272 characters (compressed mode)
Full specifications
Other Specifications
Accoustic noise:58dBA
Warranty:3 years onsite
Voltage requirements:220/230 VAC (+6%, -14%) 240V AC (+/-10%)
Weight:18Kg
Frequency:50/60 Hz
Dimensions(HxWxD):180 x 570 x 417mm
Paper Handling
Paper path 1:Bottom-feed: for specific volume-applications, heavy paper, light cardstock and labels (pull-tractor or power-tractor required)
Other media:Light cardstock: max.150 g/m2 (bottomfeed)
Optional paper handling:Single-bin Cutsheet feeder Double-bin Cutsheet feeder Pull tractorfeed (mechanical) Power-tractor (motor-powered)
Paper path 2:Top-feed: half-automatic feeding of single sheets or Cutsheet feeder for letterhead or multipart forms
Paper path 3:Rear-feed: extra flexibility: paper park function for easy switching between continuous forms and single sheets
Number of copies:8 (original + 7 copies)
Paper weight:36-90 g/m2
Standard paper handling:Push-tractor rearfeed Paper-park feature Easy tear-off without paper waste Semi-automatic feeding of single sheets
Paper dimensions:Continuous forms: 76-406mm Continuous envelopes: max. 239 x 102mm
Printing Characteristics
Print speed:Fastest:550 High speed draft @ 10cpi: 550 Data/Letter quality @ 10cpi: 417/104
Printhead:Extremely durable 9 pin print head
Printing width:136 characters (10cpi) 272 characters (compressed mode)
Character pitch:10, 12, 15, 17 and 20 cpi
Built in barcodes:Code 39, UPC-A, UPC-E, EAN 8, EAN-13, Interleaved 2 of 5, Code 128
Fonts:Courier, Gothic, Utility, Draft, HS Draft
Optional fonts:None
Graphic resolution:288 x 144dpi (max.)
Memory:28Kb
First printable line:0.5 mm from top of page
Font styles:Bold, emphasized, italics, sub-script, super-script, double width, double height
Reliability
Print head life:200M characters
Reliability:Print head life: 200M characters MTBF: 8,000 hours
Ribbon life:10M characters
MTBF:8,000 hours
Interfaces and Emulations
Interface:Centronics parallel RS-232c serial
Emulation:Epson FX IBM ProPrinter XL-III AGM
Optional emulation:OKI MicroLine Pacemark
